Texas Pneumatic replacement parts

Pneu-Light

Find Texas Pneumatic TX-PL5500 Pneu-Light repair parts and compatible assemblies using the authorized OEM parts diagram.

TX-PL5500 Parts Diagram

Texas Pneumatic TX-PL5500 exploded parts diagram. Use the diagram to identify the part you need, then select it from the parts list below.

Texas Pneumatic TX-PL5500 parts diagram

Repair Parts

Part # Description Price
TX-PL01 Pneu-Light Motor Housing $1,110.93
TX-PL02 Pneu-Light Motor Base $369.14
TX-PL03 Pneu-Light Lens Ring $121.20
TX-PL04 Lens (Sodium Lime) $158.96
TX-PL05 Lens Gasket $45.63
TX-PL06 Lens Ring Screws $4.07
TX-PL07 Led Light Engine $228.95
TX-PL08 Light Engine Screws $2.17
TX-PL10 Brass Terminal Screw $2.80
TX-PL11 Brass Flat Washer $0.95
TX-PL12 Terminal Wire W/ Ring Connector (8-10 Stud) $11.50
TX-PL13 Brass Nyloc Nut $5.33
TX-PL14 Jumper Wire W/ Ring Connectors (8-10 Stud) $15.45
TX-PL15 Heat Sink Plate $121.20
TX-PL18 Nylon Insulator $7.51
TX-PL19 Plug $1.49
TX-PL23 Stator Winding $444.42
TX-PL24 Stator Winding Screws $2.80
TX-PL25 Air Nozzle Plate $18.95
TX-PL26 Air Nozzle Plate Screws $2.17
TX-PL27 Shaft $84.12
TX-PL28 Bearing $56.63
TX-PL29 Stator Magnet $518.50
TX-PL30 Turbine $369.14
TX-PL31 Bear Hug Nut $45.63
TX-PL32 "O" Ring $11.43
TX-PL34 Bracket Bolt For Housing $11.50
TX-PL35 Stainless Bracket $51.90
TX-PL36 Stainless Knob For Bracket $37.54
TX-PL37 Knob Clip $2.80
TX-PL38 Magnetic Base For Pneu-Light $264.24
TX-PL39 Magnetic Base Screws $2.80
TX-PL41 Motor Base Screws $5.33
TX-PL16 #10-24 X 3/8" Button Socket Head Cap Screw $2.17
TX-PL17 "O" Ring $11.43
TX-PL20 Dix-Lock Female Head X 3/4" MPT (Stainless) $98.26
TX-PL21 Dix-Lock Male Locking Head X 1/2" Hose Barb W/ Ferrule (Steel) $71.41
TX-PL42 Nylon Washers For Bracket $1.49
TX-PL43 Tolerance Ring For Bearing $11.50
TX-PL44 5/32" Neoprene Washer $1.49
TX-PL45 Brass Nut $1.49
TX-PL47 Nylon Washer For Heat Sink $1.49
TX-PL33 3/4" Breather Vent - 20 Micron $14.18
TX-PL46 Valve Block Dowel Pin $2.28
TX-PL48 3/4" Square Head Plug (Galvanized) $10.54
TX-PL49 3/4" Street Elbow - Stainless $33.58
TX-PL09 Heat Sink Sil-Plate $20.49

Accessories & Consumables

Part # Description Price
TX-PL50 Safety Zone Exhaust Kit $409.75
TX-PL22 1/2" Id X 33′ - 500 Psi Hose Whip Assy W/ Qm33WF Dix-Lock Coupling & 1/2" $292.33
